ADJ VX All-In-One Video Processor LED Wall Controller | VX400

The ADJ VX series all-in-one LED wall controllers are built for production teams, AV integrators, and system designers who need a streamlined solution for driving large-format and unconventional LED display configurations. By combining video processing and LED control into a single chassis, these units eliminate the need for separate sending cards and external processors, simplifying rack builds for touring productions, fixed installs, broadcast sets, and event staging environments. Both models support conventional, curved, and irregularly shaped LED screens, making them equally suited to permanent architectural installs and touring LED walls where display geometry changes from show to show.

Powered by NovaStar's SuperView III image processing engine, the VX series delivers stepless output scaling, free input cropping, and one-click full-screen display without sacrificing image quality. Three selectable working modes, video controller, fiber converter, and bypass, give engineers flexibility to adapt the same unit to different signal routing architectures. Low-latency operation reduces the delay from input to receiving card to as low as 20 lines when low latency and bypass mode are enabled together, a critical advantage for live performance and broadcast contexts where frame delay is unacceptable. Automatic screen brightness adjustment, pixel-level brightness and chroma calibration via NovaLCT, and up to 10 user-defined presets support repeatable show recall and consistent image quality across long runs.

Input flexibility covers HDMI, DVI, 3G-SDI, and optical fiber, while multiple hot backup options between devices and between Ethernet ports protect against signal loss during live events. The VX series is available in two configurations to match the pixel load and port count required by the installation, making it a scalable choice from mid-size LED walls to large multi-cabinet arrays.
