8-inch Q-Series panel PC with Windows 11 Pro, Intel Celeron J4125, 4GB RAM, 256GB SSD

8-inch Q-Series panel PC with Windows 11 Pro

An 8 inch industrial panel PC with a 4:3 1024 x 768 capacitive screen, an Intel Celeron J4125 quad-core and dual LAN, packaged in a fanless aluminum shell for line-side visualization terminals and cell-level HMI replacements. Windows 11 Pro is pre-installed and activated before dispatch; the exact build is confirmed with your quote.

Display 8-inch TFT LCD Resolution 1024 x 768 / 4:3 Processor Intel Celeron J4125 Memory 4GB DDR4 Storage 256GB SSD Touch 10-point capacitive Brightness 300 cd/m2 Contrast ratio 800:1 Operating system Windows 11 Pro; release confirmed with quote Power input 12-36V DC Cooling Passive / fanless Front protection IP65 when correctly installed Operating temperature -10°C to 60°C Enclosure 225.5 x 185 x 64.5 mm Datasheet opening 213.3 x 172.8 mm Ethernet 2 x LAN, 1000Mbps (Realtek RTL8111H + RT8152B) USB 2 x USB 2.0 + 2 x USB 3.0 Audio 1 x audio output Video output HDMI (up to 4K) + VGA Wireless 2.4GHz/5GHz dual-band WiFi, 2 x antenna; Bluetooth 4.0 optional; SIM slot depends on 3G/4G module
